Advanced PCD Grinding Machine -13°- 24° Grinding Wheel Inclination 0.001mm Readout of Linear Gratings 1280dpi*960dpi Image System Resolution

Product Description:

The PCD Grinding Machine is a high-precision tool designed for grinding PCD/PCBN materials, making it an ideal choice for industries working with hard materials. This advanced machine is equipped with cutting-edge features to ensure precise and efficient grinding operations.

The product boasts an Image System Resolution of 1280dpi*960dpi, providing exceptional clarity and accuracy during grinding processes. With an Optical Tube Distance of 300mm, users can easily position the workpiece for optimal results.

When it comes to precision, the PCD Grinding Machine excels with its Pixel Size of 3.75um*3.75um, ensuring fine details are captured and maintained throughout the grinding process. The Grinding Wheel Inclination ranging from -13° to +24° allows for versatile grinding angles to suit various material requirements.

For added convenience and flexibility, the machine features a Cross Table sized at 210*160mm with 4T Grooves. This design enhances stability and precision during grinding operations, contributing to the overall efficiency of the machine.

Whether you are working with PCD, PCBN, or other hard materials, the PCD Grinding Machine is a reliable and high-performance solution that meets the demands of modern industrial applications. Its advanced features and precise capabilities make it a valuable asset for any workshop or manufacturing facility.

Applications:

CTSTC PCD Grinding Machine, originating from China, is a high-quality grinder designed specifically for hard materials such as PCD/PCBN tools and materials. With a CE certification, this grinder ensures reliable performance and precision grinding for various applications.

The PCD Grinding Machine is ideal for a wide range of product application occasions and scenarios. It is suitable for industries that require precision grinding of hard materials such as PCD/PCBN tools and materials. This grinder is perfect for manufacturing plants, tool and die shops, and industrial workshops where high-precision grinding is essential.

With a minimum order quantity of 1 and packaged in a sturdy plywood box, the CTSTC PCD Grinding Machine offers flexibility and convenience for customers. The delivery time of 45-60 days ensures timely fulfillment of orders, while payment terms including TT, LC, and Western Union provide options for easy transactions.

The PCD Grinding Machine features a grinding wheel oscillation distance of 0-40mm, allowing for adjustable precision grinding. Its compact dimension of 1200*1168*1530mm (L*H*W) makes it suitable for various workspace sizes. The spindle power of 2.2kw ensures efficient grinding performance, while the image magnification of 45-250 times (digital zoom) enables detailed inspection of the grinding process.

Equipped with a grinding wheel size of 150*40*40mm (D*H*T), the CTSTC PCD Grinding Machine offers versatility in grinding various hard materials with ease. Whether it's sharpening PCD/PCBN tools or grinding PCD/PCBN materials, this grinder is a reliable and efficient solution for achieving precise grinding results.

Customization:

Product Customization Services for the PCD/PCBN Tools grinder - CTSTC

Place of Origin: CHINA

Certification: CE

Minimum Order Quantity: 1

Packaging Details: plywood box

Delivery Time: 45-60 days

Payment Terms: TT/LC/Western Union

Grinding Wheel Inclination: -13°~+24°

Tip Radius: 0-70mm

Grinding Pressure: 0-450N(adjustable)

Grinding Wheel Oscillation Distance: 0-40mm(adjustable)

Net Weight: 1450kgs

Support and Services:

Our Product Technical Support and Services for the PCD Grinding Machine include:

- Installation assistance

- Troubleshooting and diagnosis

- Regular maintenance and service

- Software updates and upgrades

- Training for operators
