High Precision PCD Grinding Machine with 140mm Grinding Wheel Height Adjustment and Adjustable Grinding Pressure

Product Description:

The PCD/PCBN Grinding Machine is a heavy-duty grinder designed specifically for hard materials such as PCD and PCBN. With a net weight of 1450kgs, this machine is sturdy and durable, making it ideal for industrial applications.

Featuring a tip radius of 0-70mm, this grinder provides precision grinding for a wide range of materials. The tip radius adjustment allows for versatile grinding options, making it suitable for various applications.

Equipped with image magnification capabilities ranging from 45 to 250 times (digital zoom), this grinding machine offers enhanced visibility and precision during the grinding process. The digital zoom feature allows operators to closely examine the grinding area, ensuring accurate and efficient results.

The readout of linear gratings on this machine is an impressive 0.001mm, enabling precise measurements and control during the grinding process. This high level of accuracy ensures consistent and high-quality results, making it an essential tool for precision grinding tasks.

Overall, the PCD/PCBN Grinding Machine is a reliable and efficient tool for grinding hard materials with precision and accuracy. Its robust construction, versatile tip radius adjustment, advanced image magnification, and precise linear gratings readout make it a valuable asset for any industrial setting requiring a hard materials grinder.

Applications:

The PCD/PCBN Grinding Machine by CTSTC is a high-quality precision tool designed for grinding PCD/PCBN materials with ease and accuracy. This innovative grinding machine is manufactured in CHINA and comes with a CE certification, ensuring its compliance with international quality standards.

With a Grinding Wheel Height Adjustment of 140mm and a Grinding Wheel Size of 150*40*40mm(D*H*T), this PCD grinding machine offers versatility and efficiency in various grinding applications. The Grinding Wheel Inclination range of -13° to +24° allows for precise grinding angles, making it ideal for shaping and sharpening PCD/PCBN cutting tools.

The 2.2kw Spindle Power of this PCD grinding machine ensures high performance and consistent results, making it suitable for both small-scale workshops and industrial manufacturing settings. The minimum order quantity for this product is 1 unit, and it is packaged securely in a plywood box for safe transportation.

Whether you are in the automotive, aerospace, or woodworking industry, the PCD/PCBN Grinding Machine offers excellent grinding capabilities for various applications. Its robust construction and advanced features make it a reliable choice for tool manufacturers, sharpening services, and production facilities.

Ordering this PCD grinding machine is convenient, with flexible payment terms including TT, LC, and Western Union accepted. The delivery time for this product is 45-60 days, ensuring timely availability for your operational needs. Enhance your grinding processes and achieve superior results with the precision and efficiency of the CTSTC PCD/PCBN Grinding Machine.

Customization:

Product Customization Services for the PCD Grinding Machine:

Brand Name: CTSTC

Place of Origin: CHINA

Certification: CE

Minimum Order Quantity: 1

Packaging Details: plywood box

Delivery Time: 45-60 days

Payment Terms: TT/LC/Western Union

Cross Table Swiveling Angle: 270°

Grinding Wheel Height Adjustment: 140mm

Size of Cross Table: 210*160mm With 4T Grooves

Pixel Size: 3.75um*3.75um

Spindle Power: 2.2kw

Customization options available for PCD/PCBN materials grinder, PCD/PCBN Tools grinder, and Hard materials grinder.

Support and Services:

The Product Technical Support and Services for the PCD Grinding Machine include:

- Installation guidance

- Training for machine operation and maintenance

- Troubleshooting assistance

- Spare parts availability

- Software updates and upgrades

- Regular maintenance and servicing options
