170mm Grinding Wheel Traveling Range PCD/PCBN Materials Grinder with Adjustable 0-45/min Oscillation Frequency

Product Description:

The PCD Grinding Machine is a versatile tool designed for precision grinding of PCD/PCBN tools. It is equipped with advanced features to ensure accuracy and efficiency in grinding operations.

One of the key features of this machine is its Cross Table Swiveling Angle of 270°, allowing for flexible positioning and grinding of PCD/PCBN tools from various angles. This feature enables precise and multi-angle grinding, making it suitable for a wide range of tool geometries and specifications.

The Grinding Wheel Traveling Range of 170mm provides ample space for grinding operations, allowing for efficient and precise material removal. This extended traveling range ensures that the machine can handle a variety of tool sizes and shapes, making it a versatile solution for different grinding needs.

With a Readout of Linear Gratings at 0.001mm, the PCD Grinding Machine offers exceptional precision and accuracy in grinding operations. This high level of accuracy ensures consistent and reliable results, meeting the demands of precision tool manufacturing and sharpening.

Grinding Wheel Height Adjustment of 140mm allows for easy and precise adjustment of the grinding wheel height, catering to different tool geometries and grinding requirements. This feature enhances the machine's versatility and usability, making it suitable for a wide range of PCD/PCBN tool grinding applications.

Despite its robust features and capabilities, the PCD Grinding Machine has a Net Weight of 1450kgs, making it relatively lightweight and easy to transport within a workshop or manufacturing facility. This portability, combined with its advanced features, makes it a practical and efficient solution for tool grinding operations.

In conclusion, the PCD Grinding Machine is a reliable and high-performance tool grinder designed for precision grinding of PCD/PCBN tools. With its advanced features, including a Cross Table Swiveling Angle of 270°, Grinding Wheel Traveling Range of 170mm, Readout of Linear Gratings at 0.001mm, Grinding Wheel Height Adjustment of 140mm, and a Net Weight of 1450kgs, this machine offers precision, versatility, and efficiency in tool grinding applications.

Applications:

CTSTC PCD Grinding Machine is a high-quality precision equipment designed for grinding PCD/PCBN materials, making it an ideal choice for various industrial applications. With its exceptional performance and durability, this product is suitable for a wide range of occasions and scenarios:

- Manufacturing plants specializing in the production of cutting tools can benefit from the CTSTC PCD Grinding Machine. Its ability to grind hard materials with precision makes it an essential tool for enhancing the quality and performance of cutting tools.

- Tool and die shops looking to sharpen and recondition PCD/PCBN tools can rely on the CTSTC grinder to achieve optimal results. The machine's spindle power of 2.2kw ensures efficient grinding, while the grinding wheel inclination range of -13° to +24° allows for versatile grinding angles.

- Research and development facilities working with PCD/PCBN materials can utilize the CTSTC PCD Grinding Machine to conduct experiments and produce custom tools. The readout of linear gratings at 0.001mm enables precise control over the grinding process, ensuring consistent and accurate results.

Originating from China, the CTSTC PCD Grinding Machine is CE certified, guaranteeing its quality and compliance with international standards. Customers can place orders with a minimum quantity of 1, and the product will be securely packaged in a plywood box for safe transportation.

With a net weight of 1450kgs, the CTSTC PCD Grinding Machine is robust and stable during operation, providing a reliable solution for grinding hard materials. The machine's optical tube distance of 300mm offers flexibility in handling different workpieces, making it suitable for various grinding applications.

Customers can expect their orders to be delivered within 45-60 days, and flexible payment terms including TT, LC, and Western Union are accepted. Overall, the CTSTC PCD Grinding Machine excels in grinding PCD/PCBN materials and hard materials, making it a valuable asset for industries requiring precision grinding capabilities.

Customization:

Product Customization Services for the PCD Grinding Machine:

Brand Name: CTSTC

Place of Origin: CHINA

Certification: CE

Minimum Order Quantity: 1

Packaging Details: plywood box

Delivery Time: 45-60 days

Payment Terms: TT/LC/Western Union

Spindle Speed: 0-42000RPM(adjustable)

Grinding Wheel Traveling Range: 170mm

Image System Resolution: 1280dpi*960dpi

Pixel Size: 3.75um*3.75um

Image Magnification: 45-250 Times(digital Zoom)

Support and Services:

Our Product Technical Support and Services for the PCD Grinding Machine include:

- Installation assistance and training

- On-site maintenance and repair services

- Troubleshooting guidance and support

- Software updates and technical documentation

- Customer service and product inquiries
