PCD Grinding Machine with Grinding Wheel Inclination of -13°- 24° and Image Magnification up to 250 Times

Product Description:

The PCD Grinding Machine is a high-precision tool designed specifically for grinding PCD/PCBN materials, making it an ideal choice for hard materials grinding applications. With a net weight of 1450kgs, this machine is sturdy and durable, ensuring stable performance during operation.

Featuring a size of cross table measuring 210*160mm with 4T grooves, this grinding machine provides ample space for workpieces and offers versatility in handling various sizes and shapes of materials. The readout of linear gratings at 0.001mm ensures precise and accurate grinding, meeting the strict requirements of high-precision applications.

The image system resolution of 1280dpi*960dpi delivers clear and detailed images, allowing operators to monitor the grinding process effectively and make necessary adjustments for optimal results. The spindle speed of 0-42000RPM is adjustable, enabling users to customize the grinding parameters based on the specific material and application requirements.

Whether you are working with PCD, PCBN, or other hard materials, this PCD Grinding Machine offers exceptional performance and reliability, making it a valuable asset in precision grinding operations. Its robust construction, precise measurement capabilities, and adjustable spindle speed make it a versatile tool for a wide range of applications.

Applications:

CTSTC PCD/PCBN Grinding Machine is a high-quality product originating from China, known for its exceptional performance in grinding hard materials such as PCD (polycrystalline diamond) and PCBN (polycrystalline cubic boron nitride). With a spindle power of 2.2kw, this machine is designed to deliver precise and efficient grinding results.

The product is CE certified, ensuring its compliance with international quality and safety standards. Customers can purchase this PCD grinding machine with a minimum order quantity of 1, and it is securely packaged in a plywood box for safe transportation.

When it comes to the application occasions and scenarios, the CTSTC PCD/PCBN Grinding Machine is ideal for various industries that work with hard materials. It is commonly used in tool manufacturing facilities, metalworking workshops, and precision engineering companies.

The machine's advanced image system resolution of 1280dpi*960dpi allows for detailed and accurate grinding processes, making it suitable for intricate workpieces and complex shapes. Additionally, the readout of linear gratings at 0.001mm ensures precise control over the grinding operations, resulting in high-quality finished products.

With a pixel size of 3.75um*3.75um, the PCD grinder offers exceptional grinding precision, making it a preferred choice for businesses that demand accuracy and consistency in their operations.

Customers can expect their orders to be delivered within 45-60 days from the date of purchase, and flexible payment terms including TT, LC, and Western Union are accepted for convenience.

Customization:

Product Customization Services for the PCD Grinding Machine:

Brand Name: CTSTC
Place of Origin: CHINA
Certification: CE
Minimum Order Quantity: 1
Packaging Details: plywood box
Delivery Time: 45-60 days
Payment Terms: TT/LC/Western Union
Net Weight: 1450kgs
Grinding Wheel Traveling Range: 170mm
Grinding Wheel Oscillation Frequency: 0-45/min (adjustable)
Pixel Size: 3.75um*3.75um
Cross Table Swiveling Angle: 270°

Product Attributes suitable for: PCD grinder, Hard materials grinder, PCD/PCBN materials grinder

Support and Services:

The Product Technical Support and Services for the PCD Grinding Machine include:

- Installation and setup assistance

- Training for operators and maintenance staff

- Troubleshooting guidance

- Repair and maintenance services

- Spare parts availability
