140mm Grinding Wheel Height Adjustment PCD Grinding Machine with and 300mm Optical Tube Distance

Product Description:

The PCD Grinding Machine is a state-of-the-art tool designed specifically for precision grinding of PCD/PCBN Tools. With advanced features and specifications, this machine ensures efficient and accurate grinding for PCD/PCBN materials.

Key Product Attributes:

Pixel Size: 3.75um*3.75um

Image Magnification: 45-250 Times (digital Zoom)

Grinding Wheel Oscillation Distance: 0-40mm (adjustable)

Dimension: 1200*1168*1530mm (L*H*W)

Size of Cross Table: 210*160mm with 4T grooves

The PCD Grinding Machine offers exceptional precision and versatility in grinding PCD/PCBN tools. Its pixel size of 3.75um*3.75um ensures detailed and accurate grinding results. The image magnification capability ranging from 45 to 250 times through digital zoom provides enhanced visibility and control during the grinding process.

With a grinding wheel oscillation distance of 0-40mm, the machine offers adjustable settings to cater to various grinding requirements. This feature allows for precise control over the grinding depth and ensures consistent results across different applications.

The machine's dimension of 1200*1168*1530mm (L*H*W) provides a compact yet sturdy structure that is suitable for various industrial settings. The size of the cross table, measuring 210*160mm and equipped with 4T grooves, offers stability and support for grinding operations, enhancing the overall efficiency of the process.

Overall, the PCD Grinding Machine is a reliable and high-performance tool for grinding PCD/PCBN materials with precision and accuracy. Its advanced features and specifications make it an ideal choice for industries requiring efficient and quality grinding solutions.

Applications:

The PCD/PCBN Grinding Machine by CTSTC is a versatile and high-quality tool designed to meet the demanding needs of grinding hard materials such as PCD and PCBN. With its origin in China, this product carries the prestigious CE certification, ensuring its compliance with international standards.

Whether you are in the automotive, aerospace, or woodworking industry, this PCD grinder is the perfect solution for sharpening and regrinding PCD/PCBN materials with precision and efficiency. Its adjustable Grinding Pressure ranging from 0 to 450N allows you to customize the grinding process according to your specific requirements.

The Grinding Wheel Oscillation Frequency of 0-45/min, along with the wide Tip Radius range of 0-70mm, provides you with flexibility in achieving the desired grinding results. Additionally, the Grinding Wheel Inclination of -13° to +24° enables you to work on complex geometries with ease.

Whether you need to grind PCD inserts, PCBN cutting tools, or other hard materials, this machine is your go-to solution. The minimum order quantity is just 1 unit, and the product is carefully packaged in a plywood box to ensure safe delivery to your location.

With a delivery time of 45-60 days, you can expect to receive your PCD/PCBN Grinding Machine promptly after placing your order. Choose from a variety of payment terms including TT, LC, and Western Union to facilitate a smooth transaction process.

Customization:

Product Customization Services for PCD Grinding Machine:

Brand Name: CTSTC

Place of Origin: CHINA

Certification: CE

Minimum Order Quantity: 1

Packaging Details: plywood box

Delivery Time: 45-60 days

Payment Terms: TT/LC/Western Union

Name: PCD/PCBN Grinding Machine

Pixel Size: 3.75um*3.75um

Cross Table Swiveling Angle: 270°

Grinding Wheel Traveling Range: 170mm

Dimension: 1200*1168*1530mm(L*H*W)

Support and Services:

The Product Technical Support and Services for the PCD Grinding Machine include:

- Installation assistance and set-up guidance

- Troubleshooting support for any operational issues

- Regular maintenance recommendations and schedules

- Training sessions for operators on machine usage and safety

- Upgrades and software updates to enhance machine performance
