0-450N Grinding Pressure PCD Grinding Machine with 0.001mm Linear Gratings Readout and 0-40mm Wheel Oscillation Distance

Product Description:

The PCD Grinding Machine is a powerful and efficient tool designed specifically for grinding hard materials with precision and accuracy. This state-of-the-art machine is equipped with advanced features to ensure optimal performance and superior results.

One of the key features of the PCD Grinding Machine is its Grinding Wheel Oscillation Frequency, which is adjustable from 0 to 45/min. This allows for precise control over the grinding process, ensuring consistent and uniform results every time. The machine also offers a Grinding Wheel Height Adjustment of 140mm, providing flexibility to accommodate various workpieces and grinding requirements.

In addition, the PCD Grinding Machine is equipped with a high-speed Spindle that can be adjusted from 0 to 42000RPM. This variable speed capability allows for customization based on the specific material being ground, ensuring optimal performance and efficiency. The machine's Pixel Size is 3.75um*3.75um, providing a high level of detail and accuracy in the grinding process.

With a Net Weight of 1450kgs, the PCD Grinding Machine is sturdy and durable, capable of handling heavy-duty grinding tasks with ease. Its robust construction and advanced technology make it a reliable and efficient tool for a wide range of grinding applications.

Whether you are looking for a hard materials grinder, PCD grinder, or PCD grinding machine, the PCD Grinding Machine offers unmatched performance and precision. Its adjustable settings, high-speed Spindle, and precise control features make it the ideal choice for demanding grinding tasks that require accuracy and efficiency.

Features:

• PCD Grinding Machine
• Grinding Wheel Oscillation Distance: 0-40mm (adjustable)
• Grinding Wheel Traveling Range: 170mm
• Grinding Wheel Inclination: -13° to +24°
• Grinding Pressure: 0-450N (adjustable)
• Tip Radius: 0-70mm

Applications:

CTSTC PCD Grinding Machine is a high-quality grinding equipment designed for the precise grinding of PCD/PCBN Tools and materials. With its advanced technology and superior performance, this machine is ideal for a wide range of applications and scenarios.

Originating from CHINA, the CTSTC PCD Grinding Machine is CE certified, ensuring its reliability and compliance with international quality standards. It comes with a minimum order quantity of 1 and is packaged securely in a plywood box for safe transportation.

With a pixel size of 3.75um*3.75um, the CTSTC PCD Grinding Machine offers exceptional precision in grinding PCD/PCBN materials. Its adjustable spindle speed ranging from 0 to 42000RPM allows for versatile grinding capabilities, catering to various grinding needs.

The grinding wheel oscillation distance of 0-40mm, along with a tip radius of 0-70mm, provides flexibility and accuracy in grinding different types of PCD tools. The machine's spindle power of 2.2kw ensures efficient and consistent grinding performance.

Whether you are in the automotive, aerospace, or tool manufacturing industry, the CTSTC PCD Grinding Machine is suitable for a wide range of product application occasions. From grinding PCD inserts to sharpening PCD end mills, this machine is a valuable asset for enhancing productivity and achieving precision in tool grinding.

With a delivery time of 45-60 days, you can receive your CTSTC PCD Grinding Machine in a timely manner. Payment terms including TT, LC, and Western Union offer convenient options for purchasing this high-performance grinder.

Customization:

Product Customization Services for PCD Grinding Machine:

Brand Name: CTSTC

Place of Origin: CHINA

Certification: CE

Minimum Order Quantity: 1

Packaging Details: plywood box

Delivery Time: 45-60 days

Payment Terms: TT/LC/Western Union

Grinding Wheel Inclination: -13°~+24°

Grinding Wheel Oscillation Distance: 0-40mm(adjustable)

Name: PCD/PCBN Grinding Machine

Cross Table Swiveling Angle: 270°

Net Weight: 1450kgs

Support and Services:

The PCD Grinding Machine is a high-precision tool used for grinding polycrystalline diamond (PCD) tools and inserts. It is designed to provide efficient and precise grinding, ensuring the highest quality finish for PCD cutting tools.

Our Product Technical Support and Services for the PCD Grinding Machine include:

- Installation assistance and setup guidance to ensure proper functioning of the machine.

- Training programs for operators to maximize the performance and lifespan of the machine.

- Regular maintenance services to keep the machine in optimal working condition.

- Troubleshooting and technical assistance to address any issues or concerns with the machine.
