Grinding Wheel Oscillation Distance 0-40mm adjustable PCD/PCBN Tools grinder with Readout of Linear Gratings 0.001mm

Product Description:

The PCD/PCBN Grinding Machine is a versatile and efficient tool designed for precision grinding of PCD/PCBN tools. With its advanced features and adjustable settings, this machine is ideal for achieving high-quality results in tool manufacturing and sharpening applications.

Featuring a Tip Radius range of 0-70mm, this grinding machine offers excellent flexibility for various tool geometries and requirements. The adjustable Grinding Wheel Oscillation Distance of 0-40mm allows for precise control over the grinding process, ensuring optimal tool performance and longevity.

The PCD/PCBN Grinding Machine is equipped with a Grinding Pressure range of 0-450N, providing operators with the ability to customize the pressure based on the specific material and tool being processed. This adjustable feature contributes to the machine's versatility and ensures consistent results across different applications.

Additionally, the Grinding Wheel Oscillation Frequency of 0-45/min is another adjustable parameter that enhances the machine's performance and efficiency. By controlling the oscillation frequency, users can achieve the desired surface finish and grinding precision required for PCD/PCBN tools.

Overall, the PCD/PCBN Grinding Machine is a reliable and high-precision tool grinder that meets the demands of modern tool manufacturing and sharpening processes. Its adjustable settings, including Tip Radius, Grinding Wheel Oscillation Distance, Grinding Pressure, and Oscillation Frequency, make it a versatile solution for various grinding applications.

Whether you are looking to sharpen existing PCD/PCBN tools or manufacture new ones, this grinding machine offers the capabilities and precision needed to achieve superior results. Trust in the PCD/PCBN Grinding Machine to enhance your productivity and deliver exceptional grinding performance for your tooling needs.

Features:

• Product Name: PCD Grinding Machine
• Grinding Wheel Oscillation Distance: 0-40mm (adjustable)
• Grinding Wheel Inclination: -13° to +24°
• Size of Cross Table: 210*160mm With 4T Grooves
• Image Magnification: 45-250 Times (digital Zoom)
• Dimension: 1200*1168*1530mm (L*H*W)

Applications:

CTSTC PCD grinding machine, originating from China, is a cutting-edge tool designed for precision grinding of PCD/PCBN tools and materials. With CE certification, this high-quality machine is ideal for various industrial applications.

The PCD grinding machine by CTSTC is versatile and can be used in a wide range of scenarios. Its advanced features make it suitable for grinding PCD/PCBN tools with exceptional accuracy and efficiency. Whether in tool manufacturing facilities, machining workshops, or research laboratories, this grinder excels in delivering superior performance.

With a minimum order quantity of 1 and packaged securely in a plywood box, the CTSTC PCD grinding machine is ready for prompt delivery. The lead time for shipping is 45-60 days, ensuring that customers receive their orders in a timely manner. Payment terms including TT, LC, and Western Union provide flexibility for buyers.

Equipped with an image system resolution of 1280dpi*960dpi, the PCD grinding machine ensures precise and detailed grinding operations. The grinding wheel oscillation frequency, adjustable from 0 to 45/min, allows for customizable grinding processes. The optical tube distance of 300mm and compact dimensions of 1200*1168*1530mm (L*H*W) make this machine ergonomic and space-efficient.

Furthermore, the grinding wheel inclination ranging from -13° to +24° enhances the machine's versatility for handling various grinding tasks. Whether in automotive, aerospace, or tooling industries, the CTSTC PCD grinding machine proves to be a valuable asset for enhancing productivity and achieving high-quality results.

Overall, the CTSTC PCD grinding machine is a reliable and efficient solution for precision grinding of PCD/PCBN tools and materials. Its superior performance, coupled with ease of operation and maintenance, makes it a preferred choice for industries requiring advanced grinding equipment.

Customization:

Product Customization Services for the PCD Grinding Machine:

Brand Name: CTSTC

Place of Origin: CHINA

Certification: CE

Minimum Order Quantity: 1

Packaging Details: plywood box

Delivery Time: 45-60 days

Payment Terms: TT/LC/Western Union

Grinding Wheel Height Adjustment: 140mm

Image System Resolution: 1280dpi*960dpi

Grinding Wheel Inclination: -13°~+24°

Dimension: 1200*1168*1530mm(L*H*W)

Optical Tube Distance: 300mm

Support and Services:

The PCD Grinding Machine is designed to provide efficient and precise grinding of polycrystalline diamond (PCD) tools. Our product technical support and services include:

- Comprehensive training for operators to ensure optimal use of the machine

- Maintenance services to keep the machine operating at peak performance

- Troubleshooting assistance for any technical issues that may arise

- Upgrades and enhancements to improve the machine's capabilities

- Technical documentation and resources to aid in operating and maintaining the machine
