High Precision PCD Grinding Machine with Image System Resolution 1280dpi*960dpi and Cross Table Swiveling Angle 270°

Product Description:

PCD Grinding Machine is a versatile and high-precision equipment designed for grinding PCD/PCBN materials, commonly used in the manufacturing industry for sharpening PCD/PCBN tools. This advanced machine offers exceptional performance and accuracy, making it an essential tool for various grinding applications.

The PCD Grinding Machine features a Cross Table Swiveling Angle of 270°, allowing for flexible grinding operations and precise angle adjustments. This unique capability enables users to achieve the desired grinding angle with ease, enhancing the efficiency and accuracy of the grinding process.

With a Grinding Wheel Height Adjustment of 140mm, this machine provides users with the flexibility to adjust the grinding wheel height according to their specific requirements. This feature ensures optimal grinding performance and allows for customization based on the material being processed, resulting in high-quality and consistent grinding outcomes.

The Grinding Wheel Oscillation Distance of 0-40mm (adjustable) further enhances the versatility of the PCD Grinding Machine, enabling users to control the oscillation distance of the grinding wheel based on the application needs. This adjustable feature ensures precise and efficient grinding, making it suitable for a wide range of grinding tasks.

Equipped with a Pixel Size of 3.75um*3.75um, this PCD grinding machine offers exceptional precision and accuracy in grinding operations. The fine pixel size ensures detailed and high-quality grinding results, making it ideal for intricate and demanding grinding applications that require superior surface finish and dimensional accuracy.

Weighing 1450kgs, the PCD Grinding Machine is robust and stable, providing a reliable and durable solution for grinding PCD/PCBN materials. Its sturdy construction and heavy-duty design ensure long-lasting performance and consistent results, making it a dependable tool for high-precision grinding tasks.

In conclusion, the PCD Grinding Machine is a versatile and efficient tool designed for grinding PCD/PCBN materials with precision and accuracy. With advanced features such as Cross Table Swiveling Angle, Grinding Wheel Height Adjustment, Grinding Wheel Oscillation Distance, Pixel Size, and a sturdy build, this machine is a must-have for industries requiring high-quality grinding of PCD/PCBN tools. Invest in the PCD Grinding Machine today to experience enhanced productivity, superior grinding performance, and exceptional results for your grinding applications.

Features:

• Product Name: PCD Grinding Machine
• Grinding Wheel Size: 150*40*40mm(D*H*T)
• Grinding Wheel Traveling Range: 170mm
• Size of Cross Table: 210*160mm With 4T Grooves
• Grinding Wheel Inclination: -13°~+24°
• Image System Resolution: 1280dpi*960dpi

Applications:

CTSTC PCD Grinding Machine is a versatile tool designed for precision grinding of PCD (polycrystalline diamond) and PCBN (polycrystalline cubic boron nitride) materials. With its exceptional grinding capabilities, this machine is ideal for a wide range of applications in various industries.

Product Application Occasions and Scenarios:

- Manufacturing of cutting tools: The CTSTC PCD Grinding Machine is perfect for shaping and sharpening PCD and PCBN cutting tools used in industries such as automotive, aerospace, and woodworking.

- Tool and die making: This machine is essential for grinding hard materials like PCD, PCBN, and other superhard alloys commonly used in tool and die making processes.

- Precision engineering: The CTSTC PCD Grinding Machine is suitable for precision grinding tasks that require high accuracy and smooth surface finish on hard materials.

- Research and development: Laboratories and research facilities can benefit from the advanced features of this machine to grind and analyze PCD and PCBN materials with precision.

Key Product Attributes:

- Brand Name: CTSTC

- Place of Origin: CHINA

- Certification: CE

- Minimum Order Quantity: 1

- Packaging Details: plywood box

- Delivery Time: 45-60 days

- Payment Terms: TT/LC/Western Union

- Grinding Wheel Inclination: -13°~+24°

- Cross Table Swiveling Angle: 270°

- Image System Resolution: 1280dpi*960dpi

- Optical Tube Distance: 300mm

- Pixel Size: 3.75um*3.75um

Overall, the CTSTC PCD Grinding Machine is a top choice for businesses and professionals looking for a reliable and efficient PCD/PCBN materials grinder. Its advanced features and high precision make it a must-have tool for grinding hard materials with ease.

Customization:

Product Customization Services for the PCD Grinding Machine:

Brand Name: CTSTC

Place of Origin: CHINA

Certification: CE

Minimum Order Quantity: 1

Packaging Details: plywood box

Delivery Time: 45-60 days

Payment Terms: TT/LC/Western Union

Pixel Size: 3.75um*3.75um

Grinding Pressure: 0-450N (adjustable)

Image Magnification: 45-250 Times (digital Zoom)

Spindle Power: 2.2kw

Spindle Speed: 0-42000RPM (adjustable)

Support and Services:

The PCD Grinding Machine offers comprehensive product technical support and services to ensure optimal performance and efficiency. Our team of experts is available to assist with installation, troubleshooting, and maintenance to help you get the most out of your equipment.
