Grinding Wheel Height Adjustment PCD Grinding Machine 170mm Traveling Range Adjustable Grinding Pressure

Product Description:

A PCD/PCBN materials grinder, commonly known as a PCD grinder or PCD grinding machine, is an essential tool for precision tool manufacturing and machining applications. One of the well-known products in this category is the PCD Grinding Machine, designed to meet the demands of high-precision grinding tasks.

The PCD Grinding Machine is equipped with advanced features to ensure precise and efficient grinding operations. It offers a wide range of capabilities, including a Tip Radius ranging from 0 to 70mm, making it suitable for various grinding requirements. The Grinding Wheel Size of 150*40*40mm (D*H*T) provides ample surface area for grinding PCD and PCBN materials effectively.

One of the key features of the PCD Grinding Machine is its Grinding Wheel Traveling Range of 170mm, allowing for versatile grinding tasks and accommodating different workpiece sizes. The Grinding Wheel Height Adjustment of 140mm enables users to set the optimal grinding wheel height for improved accuracy and performance.

With an Image Magnification range of 45-250 times (digital Zoom), the PCD Grinding Machine offers enhanced visibility and precision during the grinding process. This feature allows operators to inspect the workpiece closely and make necessary adjustments for achieving the desired grinding results.

In summary, the PCD Grinding Machine is a reliable and efficient tool for grinding PCD and PCBN materials with precision and accuracy. Its advanced features, including the Tip Radius adjustment, Grinding Wheel Size, Traveling Range, Height Adjustment, and Image Magnification capabilities, make it a valuable asset for tool manufacturers and machining professionals.

Features:

• Product Name: PCD Grinding Machine
• Size of Cross Table: 210*160mm With 4T Grooves
• Grinding Wheel Height Adjustment: 140mm
• Grinding Pressure: 0-450N(adjustable)
• Name: PCD/PCBN Grinding Machine
• Tip Radius: 0-70mm

Applications:

When it comes to precision grinding of PCD (polycrystalline diamond) and PCBN (polycrystalline cubic boron nitride) materials, the CTSTC PCD grinding machine is the ideal choice. With its origin in CHINA, this high-quality machine is CE certified and offers exceptional performance for various applications.

The CTSTC PCD grinding machine is suitable for a wide range of product application occasions and scenarios, thanks to its advanced features and specifications. The machine's grinding wheel oscillation distance of 0-40mm (adjustable) allows for precise and efficient grinding of PCD and PCBN materials, ensuring optimal results with each use.

With an image system resolution of 1280dpi*960dpi, pixel size of 3.75um*3.75um, and optical tube distance of 300mm, the CTSTC PCD grinding machine guarantees high-quality and accurate grinding operations. Additionally, the grinding wheel height adjustment of 140mm enables users to customize the grinding process according to their specific requirements.

Whether you are in the automotive, aerospace, or tooling industry, the CTSTC PCD grinding machine is a versatile solution for grinding PCD and PCBN materials with precision and efficiency. The machine's minimum order quantity of 1 and packaging details in a plywood box make it convenient for individual purchases or bulk orders.

With a delivery time of 45-60 days and flexible payment terms including TT, LC, and Western Union, acquiring the CTSTC PCD grinding machine is hassle-free. Its robust construction, reliable performance, and CE certification make it a trusted choice for industries requiring a PCD/PCBN materials grinder.

Customization:

Product Customization Services for the PCD Grinding Machine:

Brand Name: CTSTC

Place of Origin: CHINA

Certification: CE

Minimum Order Quantity: 1

Packaging Details: plywood box

Delivery Time: 45-60 days

Payment Terms: TT/LC/Western Union

Pixel Size: 3.75um*3.75um

Dimension: 1200*1168*1530mm(L*H*W)

Image Magnification: 45-250 Times(digital Zoom)

Grinding Wheel Traveling Range: 170mm

Grinding Wheel Oscillation Frequency: 0-45/min(adjustable)

Support and Services:

The Product Technical Support and Services for the PCD Grinding Machine include:

- On-site installation and training

- Remote technical assistance

- Maintenance and repair services

- Spare parts availability

- Upgrades and customization options
