Precision Grinding Made Easy PCD Grinding Machine and Adjustable Grinding Wheel Oscillation Distance 0-40mm

Product Description:

PCD Grinding Machine Product Summary: The PCD Grinding Machine is a high-precision tool grinder designed specifically for PCD/PCBN tools grinding applications. With advanced features and specifications, this machine ensures efficient and accurate grinding results for various tooling needs. Optical Tube Distance: 300mm The PCD Grinding Machine features an optical tube distance of 300mm, providing ample space for precise tool positioning and grinding operations. This optimal distance allows for enhanced visibility and control during the grinding process. Grinding Wheel Size: 150*40*40mm(D*H*T) Equipped with a high-quality grinding wheel sized at 150*40*40mm (Diameter*Height*Thickness), the PCD Grinding Machine offers exceptional grinding performance and durability. The large wheel size enables efficient material removal and precise shaping of PCD/PCBN tools. Pixel Size: 3.75um*3.75um The machine's advanced imaging system offers a pixel size of 3.75um*3.75um, ensuring clear and detailed visualization of the workpiece during grinding. This fine pixel resolution enhances accuracy and control, resulting in superior grinding outcomes. Image System Resolution: 1280dpi*960dpi With an impressive image system resolution of 1280dpi*960dpi, the PCD Grinding Machine delivers high-definition imaging for precise tool inspection and alignment. This superior resolution capability enables operators to detect even the smallest imperfections and make necessary adjustments for optimal grinding results. Grinding Wheel Oscillation Frequency: 0-45/min (adjustable) The PCD Grinding Machine features a variable grinding wheel oscillation frequency ranging from 0 to 45 cycles per minute, allowing operators to adjust the oscillation speed based on specific grinding requirements. This flexibility ensures optimal grinding performance and surface finish quality for different tool materials and geometries. In conclusion, the PCD Grinding Machine is a versatile and reliable tool grinder tailored for PCD/PCBN tools grinding operations. With its innovative features, such as the 300mm optical tube distance, 150*40*40mm grinding wheel size, 3.75um*3.75um pixel size, 1280dpi*960dpi image system resolution, and adjustable oscillation frequency, this machine offers exceptional precision, efficiency, and control for achieving superior grinding results. Invest in the PCD Grinding Machine to elevate your tooling capabilities and enhance productivity in your grinding processes.

Features:

• Product Name: PCD Grinding Machine
• Readout of Linear Gratings: 0.001mm
• Spindle Power: 2.2kw
• Name: PCD/PCBN Grinding Machine
• Grinding Wheel Height Adjustment: 140mm
• Cross Table Swiveling Angle: 270°

Applications:

CTSTC PCD Grinding Machine is a high-quality grinding equipment suitable for various applications and scenarios. With its origin in China and CE certification, this product guarantees reliability and performance. The minimum order quantity is 1, and each unit comes packaged in a sturdy plywood box for safe transport.

The PCD Grinding Machine is ideal for grinding PCD and PCBN materials with precision and efficiency. Its spindle speed can be adjusted from 0 to 42000 RPM, providing versatility for different grinding needs. The machine's dimensions of 1200*1168*1530mm (L*H*W) make it compact and space-saving, suitable for various workshop sizes.

One of the key features of the CTSTC PCD Grinding Machine is the cross table swiveling angle of 270°, allowing for multi-angle grinding operations. The image magnification of 45-250 times with digital zoom ensures clear and accurate grinding results.

The PCD grinder is perfect for applications such as tool and cutter manufacturing, aerospace industry, automotive industry, and woodworking. Its versatility makes it suitable for scenarios where precision grinding of PCD and PCBN materials is required.

Customers can expect their orders to be delivered within 45-60 days, and payment terms include TT, LC, and Western Union for convenience. Whether you are a small workshop or a large manufacturing facility, the CTSTC PCD Grinding Machine is a reliable and efficient solution for all your grinding needs.

Customization:

Customize your PCD Grinding Machine with CTSTC's Product Customization Services:

- Brand Name: CTSTC

- Place of Origin: CHINA

- Certification: CE

- Minimum Order Quantity: 1

- Packaging Details: plywood box

- Delivery Time: 45-60 days

- Payment Terms: TT/LC/Western Union

- Spindle Speed: 0-42000RPM(adjustable)

- Grinding Wheel Inclination: -13°~+24°

- Spindle Power: 2.2kw

- Readout of Linear Gratings: 0.001mm

- Grinding Wheel Oscillation Frequency: 0-45/min(adjustable)

Enhance your PCD/PCBN materials grinder, PCD grinder, PCD/PCBN Tools grinder with these customizable features!

Support and Services:

The PCD Grinding Machine product offers comprehensive Product Technical Support and Services to ensure optimal performance and customer satisfaction. Our team of skilled technicians is available to provide assistance with installation, troubleshooting, and maintenance of the equipment. Additionally, we offer training programs to help users maximize the potential of the machine and achieve superior results. Our commitment to quality service means that customers can rely on us for ongoing support and expertise.
